St180 Borehole Drilling Machine Portable Hydraulic Small For Water Well

Jinzhou City Shitan Machinery Equipment CO. LTD.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

St180 Borehole Drilling Machine Portable Hydraulic Small For Water Well

  • 1
  • 2

Brand Name : ST

Model Number : ST-180

Certification : ISO 9001

Place of Origin : Hebei ,China

MOQ : 1set

Price : 20000-35000 USD

Payment Terms : T/T, Western Union,

Supply Ability : 2000 sets/month

Delivery Time : 5 -10 days

Packaging Details : Wooden Package

Product Name : ST 180 Meters OEM Customized Pneumatic Borewell Machine

Weight : 4.5T

Drilling depth : 180m

Dimension(L*W*H) : 3800*1500*2200mm

Drilling hole diameter : 105-180mm

Walking speed : 2.5km/h

Climbing angles (Max.) : 30

Equipped capacitor : 55KW

Drill pipe diameter : 76mm, 89mm

Drill pipe length : 1.5m, 2.0m, 3.0m

Contact Now

ST180 Portable Borehole New Type Hydraulic Small Water Well Drilling Machine

ST 180 Meters OEM Customized Pneumatic Borewell Machine Information

They are widely used in industrial and agriculture water project, testing well and other exploration borehole. In particular, drilling hole for geothermal heating, it can also meet the engineering basis for reinforcement, loose gravel drilling rock formation connected with a variety of engineering.Our drilling rigs are more efficiency and with low failure rate, more economic and durable, and with a high comprehensive cost performance.

ST 180 Pneumatic Borewell Machine Techical Data

Product Name

ST 180 drilling rig
Drilling hole diameter
140-254mm
Drilling depth
180m
One-time advance length
3.3m
Walking speed
2.5km/h
Climbing angles (Max.)
30
Equipped capacitor
55kw
Using air pressure
1.7-2.5mpa
Air consumption
17-31m³/min
Drill pipe length
1.5m, 2.0m, 3.0m
Drill pipe diameter
76mm, 89mm
Rig lifting force
12t
Swing speed
45-65rpm
Swing torque
3200-4600(N.m)
Dimension
3800*1500*2200mm
Weight
4500kg

When purchasing a water well drilling rig, the user shall check and accept the purchased machine, focusing on the following aspects.

1. Whether the attached documents are complete; Whether the number of the drilling rig is consistent with the corresponding documents on the drilling rig, and whether the delivery certificate of the drilling rig is consistent with the corresponding documents on the drilling rig.
2. Whether the attached items are complete: check the attached items of the drilling machine according to the packing list of attached items. The attached items include attached spare parts and attached tools (if in doubt, contact the dealer).
3. Whether the machine is in good condition, the technical state of the machine may change after consignment, and the user can further determine the state of the machine when purchasing.

ST180 Pneumatic Borewell Machine FAQ

Q 1: What kind of drilling rig do you have?

A: We mainly produce small hydraulic drilling rig, water well drilling rig, core drilling rig, engineering drilling rig, geological exploration drilling rig, etc., and we will recommend the suitable model according to your exact requirement .

Q 2: Where is the address of your company?

A: Our factory is in Jinzhou, Shijiazhuang City, Hebei Province, China

Q 3: Are you a manufacturer or a trading company?

A:We are a 20 years professional manufacturer with ISO certificate. We have a large modern drilling rig plant in Hebei, China.

Q 4: How long is your delivery time?

A: Small hydraulic drilling rigs generally take 5-7 days, and large pneumatic water well drilling rigs generally take 7-15 days. If there is an urgent order, please contact our sales in advance.

Q 5: How long is the warranty of your well drilling rig?

A: Except for consumable spare parts, the whole machine shall be one year.

Q6: How long can your air compressor be used?

A: Normally more than 10 years.

Q 7: What are the terms of payment?

A: TT, Western Union transfer.

Q8, Can you provide us with the documents for customs clearance?

A: Of course. We will send you commercial invoice, sales contract, packing list, bill of lading (FOB or CFR, CIF terms), insurance policy (if CIF terms), and certificate of origin if you need it

Q9: How is your customer service?

A: 24-hour online service. The 48 hour problem was solved (except in special cases).

Q10: How about your after-sales service?

A: 1. Provide customers with online installation and commissioning instructions.

2. Well trained engineers can serve overseas. (non epidemic impact)
