Geotechnical Exploration Soil Testing Drilling Rig 300 Meters Depth

Name: Geotechnical Exploration Soil Testing Drilling Rig 300 Meters Depth
Brand: JINZHOU SHITAN
Price: 1 USD

Quality Geotechnical Exploration Soil Testing Drilling Rig 300 Meters Depth wholesale

Brand Name : JINZHOU SHITAN

Model Number : GY-200

Certification : CE ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiation

Payment Terms : T/T, Western Union

Supply Ability : 20000 sets per year

Delivery Time : 7-12 days

Packaging Details : Standard Export Package

Product Name : GY-200 Geotechnical Exploration 300 Meters Depth Soil Test Drilling Machine

Weight : 600 (kg)

Type : Core Drilling Rig

Power Type : Diesel

Usage : Water Well

Warranty : 1 Year

Drilling Depths : 300 Meters

Drilling Hole Diameter : Customized

OEM : Acceptable

Contact Now

GY-200 Geotechnical Exploration Soil Test Drilling Machine

GY-200 Soil Test Drilling Machine

This is is a kind of portable and multi-purpose engineering drilling rig, which is suitable for the engineering geological exploration of industrial and civil buildings, railways, bridges, hydropower and other departments, as well as the construction of small-diameter foundation pile holes.

Product Parameter:

Drilling Depth		50-300m
Max Open Hole Caliber		300mm
Motor power		20 (kw)
Borehole diameter		75-300 (mm)
End Hole Caliber		75mm
Drilling Rod Diameter		60mm
Drilling Angle		90°~75°
Drill Rig Moving Stroke		300mm
Power		Diesel engine 22HP
Spindle Speed		64 128 287 557 r/min
Spindle Stroke		450mm
Max.Single Line Lifting Capacity		2400kg
Max.Single Line Lifting Speed		0.41 0.82 1.64m/s
Wirerope Caliber		13mm
Mud Pump		Diesel 170L/min
Work Pressure		1.5Mpa
Water inlet pipe diameter		40mm
Water outlet pipe diameter		30mm

Machine Feature:

Wide range if P.R.M and well-set gears

Great torque in low P.R.M, fit for coring drilling and piling hole works.

Mobile cylinder installed so that the drilling machine got a free travel of 300mm, ensured easy remove of drilling stem.

Easy to handle, high efficiency, oil hydraulic drive, low labour intensity.

Optimized structure, small volume, and lightweight.
